DALI‑2 presence detector for lighting control.
Built-in brightness sensor for automatic light adjustment.
3 digital inputs for potential-free button control.
Ceiling-mount, ideal for offices, classrooms, hotels.
Energy-saving: lights respond to presence and ambient light.
Integrates with DALI‑2 and KNX systems.
Enhances comfort and reduces energy consumption.

Ceiling‑mount KNX presence detector for indoor use
Uses PIR sensor and supports 5 independently configurable detection channels.
Rear connector provides 3 digital inputs for free‐potential contacts (buttons/switches)
Includes 12 logic blocks enabling simple/complex logic (algebraic, threshold, conditional) and features like “Virtual Holder Logic”.
Supplied via KNX bus (21‑32 V DC) and configurable via ETS
Dimensions approx Ø 81 mm × 37 mm; suitable for ceiling mounting up to ~4 m height
Perfect for energy‑saving presence detection in KNX installations.

KNX line power supply rated at 640 mA for a single KNX bus line.
Accepts input voltage AC 180‑264 V, 50/60 Hz.
Provides output voltage DC 30 V (SELV) to the KNX bus.
Built‑in choke/isolator to decouple bus line, protecting communication
Adjustable dimming/transition via rotary switches.
Ideal for theatre, conference, or complex lighting.
DIN‑rail mountable.

KNX to DMX512 gateway.
Supports up to 512 DMX channels.
8 recallable sequences for lighting scenes.
Galvanic isolation between KNX, DMX, and power.
Adjustable dimming/transition via rotary switches.
Ideal for theatre, conference, or complex lighting.
DIN‑rail mountable.

DIN‑rail KNX actuator designed for fan‑coil units (2‑pipe/4‑pipe)
Provides 4 × 0‑10 V outputs plus 3 × 16 A relays.
Two 0‑10 V outputs for proportional valves; third 0‑10 V or relays for fan speed control
3rd/4th 0‑10 V outputs can act as analog sensor inputs
Built‑in logic algorithm (2‑stage PI) for independent regulation of valves and fan speed
Includes 5 digital dry‑contact inputs; 2 inputs support NTC temperature probes.
2‑stage PI control for independent valve and fan speed regulation.

DIN‑rail KNX actuator for fan‑coil units (2‑pipe or 4‑pipe systems)
Outputs: 3 × 0‑10 V (for valves/fan speed) and 3 × 16 A relays.
One 0‑10 V output can be re‑configured as an input (0‑10 V/4‑20 mA) for external sensors.
5 digital inputs for dry contacts (buttons, window sensors, alarms).
Built‑in logic algorithm (2‑stage PI) for independent regulation of valves and fan speed
Power from KNX bus (21‑32 V DC), interconnects with building automation system.
Ideal for KNX HVAC integration (fan coils, valves, speed).

Used for fan‑coil units (2‑pipe or 4‑pipe), floor heating or generic switch actuators.
Controls up to 3 fan speeds (via relays or 0‑10 V outputs).
Controls heating/cooling valves ) with set‑point vs actual value regulation
For floor heating mode, handles up to 7 channels with time‑discrete PI control.
Supply via the KNX bus (21–30 V DC) — no extra power supply
Outputs include 5 relays rated 10 A cos φ=1 (230 V AC) + 2 analog 0‑10 V channels (10 mA)
Ideal for integrating HVAC control into a KNX building automation system (fan speeds, valves, heating/cooling)

Connects two KNX TP bus segments with galvanic isolation.
8 kB filter table reduces bus traffic.
Supports KNX Long Frames and ETS5/6 configuration.
Front buttons allow temporary filter bypass for testing
LEDs indicate status and errors on both lines.
Bus powered: main line ~5 mA, sub-line ~3 mA.
Ideal for larger KNX topologies needing line isolation and stability.

12 relay outputs rated 16 A at 230 V AC each.
Each output individually configurable for lights/load or paired for blinds/shutters.
Supports logic interlock: combining relays for advanced functions (blinds, valves, etc.).
Includes 8 logic blocks for threshold, algebraic, conditional logic.
KNX bus powered (21‑32 V DC) with standard KNX interface.
Ideal for controlling lighting, blinds, HVAC loads in residential/commercial buildings.
DIN‑rail mountable module (8 DIN modules wide).

8 relay outputs, each rated 16 A at 230 V AC.
Outputs configurable individually (for lights/loads) or in pairs (for blinds/shutters).
Built‑in 8 logic blocks for simple/complex automation programs
KNX bus powered (21‑32 V DC) via standard KNX interface..
DIN‑rail mountable module, 6 DIN modules wide
Able to control generic loads, lighting, blinds or motors using relay pairs.
Ideal for universal automation needs in KNX‑based building systems requiring up to 8 outputs
