Sonodyne CS 2131T

Home Cinema Audio Cinema Screen-Channel

The CS 2131T is a 3 way, tramplified screen speaker; product highlights and specifications are detailed below In case of receipt of damaged or defective items please report the same to our website support team by emailing at response@sonodyne.com or calling 1 800 31 31 035 to obtain a Replacement Merchandise Authorisation (RMA) number.. The request will, however, be entertained once a Sonodyne team member has checked and determined the same at his own end. Customer is not happy with the look/sound quality of a defect free product. Available in Dubai and across the UAE / GCC through LEXA Lifestyle — Sonodyne's exclusive Middle East distributor for supply, installation and calibration.

Key Features

  • 3 way design with bi-amp or triamp modes
  • Time-aligned compression and midrange drivers provide accurate imaging and minimum phase cancellations.
  • Tight directivity control and angled construction of midrange horn provides uniform coverage.
  • Specially con gured midrange phase plugs result in minimum phase cancellations resulting in intelligibility of vocals.
  • The mathematically-designed horn are keep distortion within limits.
  • Dual 15” LF enclosure available in different power ratings for different hall sizes.
  • Sturdy, compact cabinet with shallow profile
  • Controlled directivity with provision to tilt to the horn

Technical Specifications

Spec Sheet (PDF)
Specifications
DESCRIPTION3 way tri-ampilfied screen channel speaker
ENCLOSURE LFBaffle - 25mm PPB sides and back, 19mm PPB. Extensive bracing
ENCLOSURE M + HFInjection moulded industrial grade plastic
TRANSDUCER COMPLEMENTS: LF2 x 15" woofer, 3" VC
TRANSDUCER COMPLEMENTS: MF2 x 6.5", 1.5" VC
TRANSDUCER COMPLEMENTS: HF1 x 1.4" throat compression driver, 2.5" VC
NOMINAL IMPEDANCELF: 4Ω, MF: 16Ω, HF: 8Ω
CONTINUOUS POWER HANDLINGLF: 800W; MF: 200W, HF: 85W
PROGRAM POWERLF: 1600W; MF: 400W, HF: 170W
PEAK POWERLF: 3200W; MF: 800W, HF: 340W
SENSITIVITY (1W/1M)LF: 101dB; MF:107dB; HF:115dB
MAX CONTINUOUS SPLLF: 130dB; MF:133dB; HF:134dB
MAX PEAK SPLLF: 136dB; MF:139dB; HF:140dB
FREQUENCY RANGE (- 3dB)40Hz ~ 17kHz
FREQUENCY RANGE (-10dB)30Hz ~ 18.5kHz
NOMINAL COVERAGEH 90° x V -30°/+20°
CROSSOVER FREQUENCYRecommended 400Hz; 1.3kHz
INPUTSScrew type barrier strip
FINISHLF - Black PVC, HF - Black, Brackets - black powder coated
M+HF/HF MOUNTING BRACKET and hardwareProvided, for mounting on top of LF cabinet
PRODUCT DIMENSION H x W x D (LF)883mm x 762mm x 450mm
PRODUCT DIMENSION H x W x D (M+HF)1054mm x 762mm x 450mm
SHIPPING DIMENSION (LF)1150mm x 892mm x 580mm
SHIPPING DIMENSION (M+HF)1146mm x 910mm x 580mm
NET WEIGHT (LF)55kg
NET WEIGHT (M+HF)30kg
GROSS WEIGHT (LF)58kg
GROSS WEIGHT (M+HF)32kg

Confirm the exact model, interfaces and installation requirements against current product documentation before specification.
