Products
Sonodyne
Sonodyne CS 3322

Sonodyne CS 3322

Request current UAE pricing and availability.

Sonodyne CS 3322
Sonodyne

Sonodyne CS 3322

Request current UAE pricing and availability.

    Home Cinema Audio Cinema Surround Speakers

    CS 3322 is a compact cinema surround loudspeaker. It is a 2 way system with a 10" woofer and compression driver with 90° x 90° directivity. With impressive power and SPL levels this is an excellent solution for an immersive cinematic experience.

    Model data

    Brand
    Sonodyne
    Series
    cs-3320-series
    Category
    Home Cinema Audio

    Key Features

    • CS3322 features a 10 inch woofer with a 2 inch voice coil and a 1 inch compression driver with 1.35 inch voice coil

    Technical Specifications

    Specifications
    DESCRIPTIONCinema surround
    ENCLOSUREMDF
    LOW FREQUENCY TRANSDUCER1 x 10 inch woofer, 2 inch voice coil
    HIGH FREQ TRANSDUCER1 x 1 inch throat, 1.35 inch voice coil
    NOMINAL IMPEDANCE8Ω
    CONTINUOUS POWER HANDLING200W
    PROGRAM POWER400W
    PEAK POWER800W
    SENSITIVITY (1W/1M)95dB
    MAX CONTINUOUS SPL118dB
    MAX PEAK SPL124dB
    FREQUENCY RANGE (- 3dB)60Hz ~17kHz
    FREQUENCY RANGE (-10dB)55Hz ~ 18kHz
    NOMINAL COVERAGE90° x 90°
    DOWNWARD FIRING ANGLENominal 20°
    INPUT CONNECTIONSBinding post
    FINISHBlack
    PACKINGPairs
    MOUNTING4 x inserts at back for wall mounting with optional wall mount bracket: CS 3300 WB
    PRODUCT DIMENSION HxWxD486mm x 360mm x 234mm
    SHIPPING DIMENSION435mm x 564mm x 500mm
    NET WEIGHT11.3kg
    GROSS WEIGHT25.6kg

    The manufacturer's previous PDF link is no longer available. Request the current datasheet before final specification.

    Confirm the exact model, interfaces and installation requirements against current product documentation before specification.
