Sonodyne DE 4380
Sonodyne

Sonodyne DE 4380

Residential Audio Amplifiers

The DE 4380 is a 8 channel power amplifier that delivers 100 watt per channel at less than 0.5% THD. A compact and fanless D Class design, it runs cool and efficient. It accepts both unbalanced RCA as well as balanced XLR inputs and outputs are rugged binding posts. Both table-top and rack mountable, it is ideal for home theatre and commercial installation application Unclipped 100 watt RMS into 4 ohm, all 8 channels driven together, total of 800W RMS DC at amplifier output, Power on/off surge, overheat, short-circuit, RFI. Available in Dubai and across the UAE / GCC through LEXA Lifestyle — Sonodyne's exclusive Middle East distributor for supply, installation and calibration.

Key Features

  • High Power
  • Class D amplifier
  • SMPS with active power factor correction
  • Protection
  • Auto Power On Off
  • Balanced and Unbalanced Inputs
  • Indicators
  • Included in the box
  • Sonic superiority
  • Akash Banerjee (DeshBhakt)

Technical Specifications

Spec Sheet (PDF)
SYSTEM
DESCRIPTION8 channel power amplifier
AMPLIFIER TYPEClass D
INPUT8 x Balanced LINE input via XLR socket, 8 x Unbalanced LINE input via RCA socket
SWITCHESPower switch and status indicator on/off on front panel
INDICATORSPower on and Auto power indicator, Status indicator , Clip indicator, Fault indicator, Mains over voltage protection
OUTPUTSpeaker output for 8 channels via touch-proof binding posts
INPUT SENSITIVITY700mV
INPUT IMPEDANCE22kOhm
FREQUENCY RESPONSE20Hz ~ 20kHz, ± 3dB
SIGNAL TO NOISE RATIO>90dB
THD (1kHz)less than 0.5
CONTINUOUS POWER100 Watt into 4Ohm per channel, 60W into 8Ohm per channel
GENERAL
PROTECTIONDC at amplifier output, Power on/off surge, overheat, short-circuit, RFI
MAINS OVER-VOLTAGE PROTECTIONYes > 260V AC
POWER REQUIREMENT230V AC 50Hz
POWER SUPPLY TYPESMPS
FINISHChassis and cover black powder coated, aluminium dial black anodised
DIMENSIONS (WxHxD)430 x 100 x 433 mm
NET WEIGHT8.5kg
