Russound MBX-AMP

MBX-AMP combines Wi-Fi streaming with a two-channel amplifier for a single audio zone. Confirm supported streaming services, network setup and any required installer activation before use.

Technical Specifications

Manufacturer specifications

Frequency Response20Hz to 20KHz

Speaker Output50 Watts Per Channel @ 8ohms, 70 watts @ 4 ohms

Audio OutputsAnalog Stereo RCA, Digital Optical, RCA Subwoofer Out (Analog Output configurable via software as fixed or variable)

Line Audio Output2V rms

Audio Inputs3.5mm Analog Stereo Audio, Digital Optical, USB2.0 Media Playback

Communication PortsEthernet RJ45 10/100 BaseT

Wi-Fi802.11ac, dual band

Bluetooth Audio SupportYes

Subwoofer Out Low Frequency Filter80Hz

Trigger Output12vDC @100mA

Music File FormatsMP3 (CBR, VBR), WAV (8, 16-bit), OGG Vorbis, FLAC (8, 16-bit), AAC, AAC+ (supports up to 24-bit/192kHz)

Power Requirements100-240V~50/60Hz, 4A

Product Dimensions8.25”W x 7”D x 1.75”H (21cm W x 17.8cm D x 4.5cm H)

Product Weight1.5 lb (0.68 kg)

Verify zone/source connections, supported network services and the supplied mains version. Optional accessories and third-party compatibility are model-specific, not brand-wide.
